型号 model
|
|
unit
|
cpcd30
|
|
动力形式power type
|
|
|
内燃 diesel
|
|
额定起重量rated capacity
|
|
kg
|
3000
|
|
载荷中心距load center
|
d
|
mm
|
500
|
|
标准起升高度lift height
|
h2
|
mm
|
3300
|
|
门架倾角(前/后)mast tilt angle (forward/backward)
|
α/β
|
deg
|
10/12
|
|
轴距 wheel-base
|
l4
|
mm
|
1850
|
|
轮距（前/后）tread(front/rear)
|
b4/b5
|
mm
|
1350/1290
|
|
行车制动 travel brake
|
|
|
液压-踏板式hydraulic-foot pedal
|
|
停车制动 parking brake
|
|
|
机械-手动式mechanical-hand lever
|
|
起升速度（满载）lift speed(with load)
|
|
mm/s
|
380/520
|
|
下降速度（满载/空载）lower speed (with/without load)
|
|
mm/s
|
满载(with load)＜600 ，空载(without load)＞300
|
|
行驶速度（空载）travel speed (without load)
|
|
km/h
|
20/25
|
|
最大爬坡（满载）max. gradeability (with load)
|
|
%
|
20
|
|
发动机 engine
|
型号 model
|
|
|
a498bpg
|
|
制造商 manufacturer
|
|
|
新昌xinchang
|
|
额定功率 rated power
|
|
kw
|
45/2500
|
|
最大扭矩 max. rotation
|
|
nm/rpm
|
193/1800
|
|
排量displacement
|
|
l
|
3.168
|
|
蓄电池 battery
|
电压 voltage
|
|
v
|
12
|
|
容量 capacity
|
|
ah
|
100
|
|
变速箱 gearbox
|
传动形式transmission type
|
|
|
液力 hydraulic
|
|
档位（前/后）gears,speed (front/rear)
|
|
|
ⅰ/ⅰ
|
|
轮胎 tire
|
类型 type
|
|
|
充气胎 pneumatic tyre
|
|
型号 model
|
前 front
|
|
|
14-17.5-14pr
|
|
后 rear
|
|
|
10-16.5-10pr
|
|
自重self.weight
|
|
kg
|
4600
|
|
自由起升高度free lift height
|
h4
|
mm
|
120
|
|
货叉fork
|
厚度×宽度×长度 thickness×width×length
|
c×b×a
|
mm
|
40×125×1070
|
外形尺寸
overall dimensions
|
全长（不带货叉）overall length(without forks)
|
l2
|
mm
|
2930
|
|
全宽overall width
|
b1
|
mm
|
1800
|
全高
overall height
|
门架升起时extended height(mast)
|
h1
|
mm
|
4650
|
|
门架未升起lower height(mast)
|
h3
|
mm
|
2342
|
|
护顶架overhead guard
|
h7
|
mm
|
2452
|
|
最小转弯半径min. turning radius
|
wa
|
mm
|
3050
|
最小离地间隙
min. under ground clearance
|
门架处 under mast
|
m1
|
mm
|
220
|
|
轴距中点处center of wheel-base
|
m2
|
mm
|
315
|
